双头双动探针 / Double Pin

GD061L1185RR

 Mechanical
Spring Force: 18.0gf±20% @0.80mm
Recommended Travel: 0.80mm
Full Travel: 3.60mm

 Material
Top Plunger – BeCu (Au Plated)
Bottom Plunger – BeCu (Au Plated)
Barrel – PBT (Au Plated)
Spring – SWP (Au Plated)

 Electrical Spec.
Resistance: Max 170mΩ
Current Rating: 4.5A
